Tutorial: Distributed Sequencer

This tutorial shows how to create a sequence, allocate individual values, reserve ranges, and use idempotency keys for safe retries.

Create a Sequence

Start kahuna-cli and create an orders sequence:

kahuna-cli> create-sequence orders 0 1
r0 created orders current 0 increment 1 max -

The arguments are:

• orders: sequence name.
• 0: initial value.
• 1: increment.

With these defaults, the first allocated value is 1.

For a sequence that should commit every value individually, create it with a per-sequence block size of 1:

kahuna-cli --create-sequence invoices --initial-value 0 --increment 1 --block-size 1

Allocate One Value

kahuna-cli> next-sequence orders create-order-1001
r1 next orders 1

The optional second argument is an idempotency key. If the client retries the same operation after a timeout, using create-order-1001 again returns the same allocation instead of consuming another value.

Reserve a Range

Reserve five IDs for a worker:

kahuna-cli> reserve-sequence orders 5 worker-a-batch-1
r2 reserved orders 2..6 count 5

The worker can now use 2, 3, 4, 5, and 6 locally without making another network call for each ID.

Inspect the Sequence

kahuna-cli> get-sequence orders
r1 get orders current 1000 increment 1 max - block default incarnation 0

current 1000 means the highest reserved value is 1000. With larger block sizes, current may be ahead of the last value your application consumed because the owner reserves blocks durably before handing values out.

Update a Sequence

Use update-sequence to change the reserved high-water mark or retune the per-sequence block size without deleting the sequence:

kahuna-cli --update-sequence orders --current-value 5000 --block-size 100

The next allocation returns 5001. The update starts a new incarnation and takes about one server SequencerBlockLease to return. During that short wait, allocations for the sequence return MustRetry.

Use Single-Command Mode

The same workflow can be run without entering interactive mode:

kahuna-cli --create-sequence invoices --initial-value 1000 --increment 1
kahuna-cli --update-sequence invoices --current-value 5000 --block-size 100
kahuna-cli --next-sequence invoices --idempotency-key invoice-req-1
kahuna-cli --reserve-sequence invoices --count 10 --idempotency-key invoice-batch-1
kahuna-cli --get-sequence invoices

Use a Client

.NET

using Kahuna.Client;

var client = new KahunaClient("https://localhost:8082");

await client.CreateSequence("orders");

long orderId = await client.NextSequenceValue(
    "orders",
    idempotencyKey: "create-order-1001"
);

KahunaSequenceRange batch = await client.ReserveSequenceRange(
    "orders",
    count: 5,
    idempotencyKey: "worker-a-batch-1"
);

Console.WriteLine($"Next order: {orderId}");
Console.WriteLine($"Reserved: {batch.Start}..{batch.End}");

TypeScript

import { KahunaClient } from "kahuna-client";

const client = new KahunaClient({
  endpoints: ["https://localhost:8082"]
});

await client.createSequence("orders");

const orderId = await client.nextSequenceValue("orders", {
  idempotencyKey: "create-order-1001"
});

const batch = await client.reserveSequenceRange("orders", 5, {
  idempotencyKey: "worker-a-batch-1"
});

console.log(`Next order: ${orderId}`);
console.log(`Reserved: ${batch.start}..${batch.end}`);

Clean Up

kahuna-cli> delete-sequence orders
deleted

Deleting a sequence removes the named counter. Creating the same sequence again starts it from the new creation parameters.
